KEEWAY HURRICANE Maintenance Manual

114
CLUTCH
Unit: mm(in)
ITEM STANDARD LIMIT
Clutch wheel inner diameter 112.00-112.15(4.410-4.415) 112.5(4.429)
Clutch shoe thickness 1.8(0.071) 1.2(0.005)
Clutch engagement 3000±300r/min
Clutch closedown 6000±300r/min
TRANSMISSION SYSTEM+DRIVING CHAIN UNIT：mm(in) EXCEPT RATIO
ITEM STANDARD TOLERANCE
Final reduction ratio / /
Gear reduction ratio / /
Drive belt width 16.8-17.2(0.6614-0.6772) 16.4(0.6457)
Driven face spring free distance 69(2.72) 64.5(2.54)
CARBURETOR
Manufacturer and type SANGUO, flat inhale stopper type
Identification code PZ19JB
Throat tube diameter 19mm
Main jet size #80
Pilot jet size #57.5
Oil needle clamp position 3nd groove
Idle air adjusting screw
Extrude 1
2
1
±
2
1
turnout
Float height
13±1mm
ELECTRICAL UNIT：mm(in)
ITEM SPECIFICATION NOTE
Ignition timing 15
0
AT 1500RPM
TYPE E7RTC(NANJING) Spark plug
GAP
0.5~0.7mm（0.020~0.028）
Spark performance Over 8 (0.3) at 1 atm
Ignition coil resistance Primary /secondary
0.2Ω~0.3Ω/7KΩ~10KΩ
Plug cap-ground
ITEM SPECIFICATION NOTE
Lighting <2Ω
Gree/Red－GROUND
Charging <2Ω
White －Ground
Magneto coil resistance
Exciting 200±20Ω at 20℃
Blure／White or Gree／
White－Ground
Generator no-load voltage More than 52v at 5000r/min
Regulated voltage More than 12-14V at 5000r/min

KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
