KEEWAY HURRICANE Maintenance Manual

53
 Insert the spacer④
 Position the movable drive face subassembly
on the crankshaft as shown in illustration.
NOTE ：
：：
：
Thoroughly clean the belt contact to be free
from oil.
 Install the fixed drive fan①.
 tighten the nut to the specified torque with
special tool.
Connecting rod fixer
Tightening torque：40-60N.M
(4.0-6.0kg-m, 29.0-43.5Ib-ft)
 fill grease in the groove provided inside
sliding surface of the kick driven gear and
install ② on the end of the crankshaft.
Wipe pff excess grease.
QIANJIANG super grease
Install washer③ and spring④.
NOTE:
When Installing washer ③， face the resin
surface of washer to outside.
 install the retainer⑤.
 continue turning the fixed drive face⑥ by hand
until the belt is seated in and both the
drive and driven faces⑦ will move
together smoothly with slip.


KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
