KEEWAY HURRICANE Maintenance Manual

66
CHARGING AND LIGHTING SYSTEM
The charging system uses the flywheel magnetoas shown in the
figure. The charging and lighting coils are mounted on the
magneto stator and generate AC as the flywheel rotor turns. AC
generated in the charging coil flows to the regulator/recifier which
changes AC to DC. The DC Then charges the battery.
Charging output check
start the engine and keep it running at 5000r/min
with lighting switch turned on.
NOTE:
When making the test, be sure that the
batteryis in fully charged condition.
Tachometer
Standard charging output：
：：
：13-16v at 5000r/min
Fuse
Battery

KEEWAY HURRICANE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Height	1120 mm
Engine Type	Single cylinder, 4-stroke
Max Torque	9.2 Nm @ 6500 rpm
Cooling System	Air cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
