78
LEGSHIELD AND PEDAL REMOVAL
1. Remove power lock housing ② by unscrewing bolt①.
3. remove legshield and pedal by unscrewing
the four bolts③
Legshield and pedal installation
4. the sequence of legshield and pedal is the reverse of reomval；
②
③
①
