11
POWERED SUBWOOFER
PARTS LIST
POWER AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
10 4701-101J-2 RCF 1/8W 100R 5% AT R81, 83, 110, 111, 114, 115, 116,
117, 120, 121
2 4701-102J-2 RCF 1/8W 1K 5% AT R145,146
10 4701-103J-2 RCF 1/8W 10K 5% AT R85, 88, 89, 92, 99, 100, 101,
103, 130, 137
3 4701-104J-2 RCF 1/8W 100K 5% AT R96,131,132
2 4701-123J-2 RCF 1/8W 12K 5% AT R95,109
1 4701-124J-C RCF 1/8W 120K 5% ATS R80
1 4701-474J-C RCF 1/8W 470K 5% ATS R86
3 4701-153J-2 RCF 1/8W 15K 5% AT R82,104,105
1 4701-154J-2 RCF 1/8W 150K 5% AT R90
2 4701-183J-2 RCF 1/8W 18K 5% AT R134,135
2 4701-202J-2 RCF 1/8W 2K 5% AT R98,147
2 4701-203J-2 RCF 1/8W 20K 5% AT R84,93
1 4701-243J-2 RCF 1/8W 24K 5% AT R97
1 4701-272J-2 RCF 1/8W 2.7K 5% AT R108
2 4701-333J-2 RCF 1/8W 33K 5% AT R136,138
1 4701-334J-2 RCF 1/8W 330K 5% AT R102
2 4701-391J-2 RCF 1/8W 390R 5% AT R106,107
1 4701-473J-2 RCF 1/8W 47K 5% AT R87
1 4701-514J-2 RCF 1/8W 510K 5% AT R91
3 4701-562J-2 RCF 1/8W 5.6K 5% AT R124,125,126
3 4701-563J-2 RCF 1/8W 56K 5% AT R129,133,139
1 4701-913J-2 RCF 1/8W 91K 5% AT R94
1 4707-152J-2 RCF 1/2W 1.5K 5% AT R140
4 4718-100J-C-X RMF 1W 10R 5% ATS METAL OXIDE R112,113,127,128
2 4719-222J-1-X RMF 2W 2.2K 5% AL METAL OXIDE R141,142
4 474B-0R1J-1 RWR 5W 0.1 5% AL R118,119,122,123
2 474B-271J-1 RWR 5W 270R 5% AL R143,144
1 4756-2036-3-15 SVR B20K H3 NVZ6TL1 6.3X6.8 HDK TP1
2 4804-0010-2 DIODE 1N4001 AT D9,10
1 4840-0720-0 BRIDGE 8A BR84 RECTRON D11
8 4840-8060-2 DIODE 1N4148 NS D3,4,5,6,7,8,12,13
1 485D-1390-5 TR BD139-10 PHILIPS HFE63-160 Q14
1 4860-1260-5 TR 2N3906 SAMSUNG RL Q9
1 4860-1430-5 TR BD140-10 HFE 63-160 Q15
2 4860-8890-0 TR MPS A06 VCE 80V NS Q12,13
2 4860-8910-0 TR MPS A56 VCE 80V NS Q11,20
1 8910-0196-0 THERMISTOR NTH4G 10K 1% MURATA TH1
2 8910-0492-0 CE 63V 12000µF 20% RL 36X45 C59,60
1 1725-296A-0002 PCB POWER AMP REV:E FC380
2 4860-5050-5 TR 2SC5200 T0-3P (L) TOSHIBA Q17,19
2 4860-5060-5 TR 2SA1943 T0-3P (L) TOSHIBA Q16,18
