KEF PSW 2000 Service Manual

13
POWERED SUBWOOFER
PARTS LIST
1 8900-5760-0 8"WOOFER F-SUB
1 7011-6220-0 H05VV-F 0.75MM/3C 2M BLK *EU
1 7011-5030-0 TC1490GP 3CORE CORD 1/P *UK
1 7011-6210-0 SJT #18 /3C 2M BLK POWER *US
8" SPEAKER ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
POWER CORD CABLE ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
PRE AMP & POWER AMP ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1 5400-3351-0 HEAT SINK FC380C Q16,17,18,19
1 5400-3361-0 HEAT SINK PLATE FC380C HEAT SINK
7 6360-0011-0 PLASTIC CABLE TIE 97MM T1/IEC1/SPK
2 7010-2217-0 250 T'NAL ASSY L=120MM RED IEC1
2 7010-2218-0 250 T'NAL ASSY L=100MM RED SW3
2 7010-2219-0 250 TNAL ASSY L=100MM BROWN SW3
1 7010-2223-0 RING T'NAL ASSY L=80MM G/Y EARTH
1 7010-2236-0 250 TNA'L ASSY L=130MM BROWN IEC1
1 7010-2237-0 HOUSING ASSY JP2411-8P L=100 FOR SPK/IN

KEF PSW 2000 Specifications

General

Signal to noise ratio	>90dB
Power consumption	300 W
Inputs	Line-level, Speaker-level
Type	Powered Subwoofer
Crossover Frequency	40 Hz - 150 Hz
