POWERED SUBWOOFER
12
PARTS LIST
VOLT SELECTOR SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
2 153Z-103M-5-7T CM 275V 0.01UF 20% RL 18X10.5 C69,70
1 5200-3627-0 SL14-22AH (1A) SW 2P2T AC SELECTOR SW2
1 1723-780A-0000 PCB VOLT SELECTOR REV:C FC310C
14 2101-1231-0 SPADE TERMINAL 6.3X0.8 STRAIGHT 1, 2, 3, 4, 5, 6, L, N,
SW2-1, SW2-2, SW2-3,
SW2-4
PRE AMP & POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1402-3070-0 X'FORMER MTG. BKT T1
1 1403-6420-0 REAR PANEL FC380C T1
1 153Z-104M-5-7W CM 275V 0.1µF 20% RL 18X12 PCX2 335M MD104 PILKO C63
1 1725-327A-0000 INSULATION PCB-3 PANEL
1 1806-2415-0 TT-00018 TOROIDAL TRANSFORMER 15V/230V T1
4 2103-7001-0 BINDING POST RED SPK IN+
4 2103-7101-0 BINDING POST BLK SPK IN-
3 2436-6501-1 VOL/FREQ KNOB VR FREQ PHAS
8 2600-3005-0800 METAL WASHER M3X0.5X8MM ZNC PWRM-PCB, Q16. 17,
18, 19
8 2600-5008-1000 METAL WASHER M5X0.8X10MM YZ SPK IN+
1 2606-3005-0643 INT TEETH WASHER M3X0.5X6.4MM BZ PANEL
1 2606-4008-0853 INT TOOTH WASHER M4X0.8X8.5MM BZ EARTH
15 2607-3009-0550 SPRING WASHER M3X0.9X5.5MM ZNC FOR PCB,IEC1,PWRM
PCB, Q16, 17, 18, 19,
VOLT-PCB
5 2607-4010-0704 SPRING WASHER M4X1X7MM NI EARTH
2 2640-3022-0540 M3 NUT IEC1
5 2640-4030-0704 NUT HEX M4 EARTH,T1
2 2842-6213-0 METAL WASHER (6X1.0X13MM) T1
2 2904-2608-3000 SCREW BH M2.6X 8 MM BZ CROSS FOR PANEL,FOR PCB
8 2904-3006-3000 SCREW M3X6 BINDING (BLK) PANEL,VOLT-PCB
2 2904-3010-3000 SCREW M3X10 (BLK) IEC1
5 2904-4010-3000 SCREW M4X10 (BLK) PANEL,T1
5 2954-3008-3000 T3X8MM SELF TAPPING H.S,RCA1
4 2954-3010-3000 B-TITE 3X10MM (BLK.ZN) H.S
8 2954-3014-3000 B-TITE 3X14MM(BLK.ZN) Q16,17,18,19
4 3100-3171-0 MICA SHEET A (24X20) Q16,17,18,19
1 4133-2090-0 2204-3 MTG BKT PWRM PCB
4 4135-0271-0 BRASS TUBE 6XM3X12MM REAR PANEL
1 4153-1250-0 2209 SW COVER 1-41-112 SW1
1 4153-3800-0 POWER INLET SOCKET SC9F-21 IEC1
2 5120-0079-0 FUSE T3.15A 250V 5X20MM UR & SEMKO IEC1
1 5200-4725-0 SWITCH ROCKER 2P1T SW2
To Next Page
