POWERED SUBWOOFER
10
PARTS LIST
PRE AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
2 4701-123J-2 RCF 1/8W 12K R20, 43
2 4701-912J-2 RCF 1/8W 9.1K R4, 27
1 7010-2221-0 3 PIN SHIELD WIRE ASSY L=130MM CN1
1 7010-2222-0 3 PIN FLAT CABLE ASSY L=100MM CN2
1 7011-3240-0 2254 1533 #26 2X2PIN BRN 100MM 1-51-112 CN4
2 7011-4570-0 AMP108U AWG26 180MM BRWN NALX2 1-51-274CN5,6
2 8910-0042-0 CE 50V 300µF RL 10% NON-POLARITY C6,14
1 1725-296A-0002 PCB POWER AMP REV:E FC380C
4 150F-101K-5-IEA CC 50V 100P 10% RL 5X3 C39,40,64,65
2150F-104M-N-FD CC 50V 0.1µF 20% RLF C53,54
1 150F-334M-N-JJA CC 50V 0.33µF 20% RLF MONO C36
1 150F-470K-5-IEA CC 50V 47P 10% RL 5X3 C38
2 150F-471K-5-IEA CC 50V 470P 10% RL 5x3 C32,33
2 150F-681J-5-OI CC 50V 680PF 5% RL 8X5 C42,43
2 150H-472M-5-IE CC 100V 4700PF 20% RL 5X3 TEC C61,62
1 153H-102K-5-INA CM 100V 0.001µF 10% RL 5X7.5 C37
3 153H-104K-5-QUA CM 100V 0.1µF 10% RL 9X11 CENTRALAB C35,57,58
1 153H-224K-5-VYA CM 100V 0.22µF 10% RL 11.5X13 C47
1 153I-154J-9-NL CM 63V 0.15µF 5% RB 7.5x6.5 C31
2 157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C55,56
1 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C50
2 157F-105M-5-IU CE 50V 1µF 20% RL 5x11 C34,48
2 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C41,66
1 157F-474M-5-IU CE 50V 0.47µF 20% RL 5X11 C51
2 157I-107M-5-SX CE 63V 100µF 20% RL 10X12.5 C44,45
1 157I-476M-5-OV CE 63V 47µF 20% RL 8X11.5 C52
1 157Q-476M-5-LUA CE 35V 47µF 20% RL 6.5X11 ELNA C49
1 1806-2393-0 TT-9904 LE 1012A 1X12TX6MM SPRING COIL L1
3 2101-1231-0 SPADE TERMINAL 6.3X0.8 STRAIGHT AC1.AC2,VO
1 3130-3020-0 IC LM7915CT REGULATOR U15
1 3130-3030-0 IC LM7815CT REGULATOR U14
1 3130-3550-0 IC TA7317P U13
1 3130-4080-0 IC TL072CP DUAL FET OP AMP T1 U12
1 3130-9150-0 IC LM3080N OTA NATIONAL U9
2 3131-7220-0 IC TL062 LOW POWER JFET U10,11
2 4132-1551-0 TERMINAL OUT PUT SPK+, SPK-
1 4500-8090-0 RELAY RUDH-SH-124D "GOOD SKT" RLY1
POWER AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
