Keiser M3 - Computer Battery and Handlebar Assembly; Battery Replacement Procedure; Handlebar Assembly Steps

Step 7: Balance the Adjustable Handlebars on the Bottom Slide.
Step 8: Locate the L-Handle Assembly, you will need to disassemble it in the following
step.
Step 9: Using a 5mm Allen wench remove the Screw and Washer, releasing the Handle Stud.
Step 10: Clean Screw thread with alcohol, then apply Loctite 242 to leading edge of
screw thread for handle bar adjust screw.
Step 11: Assemble Handle Stud and the Handlebar Spacer.
Step 11: Use assembled Handle Stud and Handlebar Spacer to mount the Adjustable
Handlebars to the Bottom Slide.
1211
7 8
8
9
Handle Stud
Spacer
10
