FLYWHEEL GUARD INSTALLATION
Step 1: Make sure to have all parts and tools present prior to assembly.
Step 2: Assemble the brackets (B) to the tube (C) With the bolt and nut (A) nger tight.
PARTS INVENTORY
A) Bolt and Nut B) Brackets C) Tube
A
B
C
1
2
Step 3: (Next Page) Make sure the ywheel is centered in the middle of the 2x4 tube of the
base frame. Remove the two (6mm allen) screws and washers from the base frame. These
screws will be used to mount the ywheel guard in step 6.
Step 13: Hand Tighten the assembly.
Step 14: Fit the L-Handle to the Handle Stud. Position the L-Handle making sure that it is
pointing to the front of the M3
+
. Install the Screw and Washer. Make sure it is snug.
1413
15
9
Step 14: Loosen the L-Handle counter-clock wise. Slide the Handlebars back and forth,
making sure they can move freely and be locked into all positions on the Bottom Slide.
