3: Operation Model 2001-TCSCAN Scanner Card Use
3-6 2001-TCSCAN-900-01 Rev. A / April 2018
Selecting a measurement function assigns it to the channel you selected. To assign the same
measurement function to all selected channels, select the same measurement function for each
channel.
Run a scan
Once the scan is set up, you can run it.
To start the scan from the front panel, use one of the following:
• Press the TRIGGER key.
• On the Scan menu, select Start.
• On the Scan swipe screen, select Start Scan.
• From the trigger mode indicator on the home screen, select Initiate Scan.
You can pause the scan from scan swipe screen on the front panel. Select Pause Scan. To continue
the scan, select Resume Scan.
Stop a scan
You can stop a running scan.
When you stop a scan, the channels remain in the state they were in (opened or closed) when the
scan was stopped.
To stop a scan from the front panel:
Select Abort Scan from the Scan menu, the Scan swipe screen, or the trigger mode indicator on the
home screen.
• On the Scan menu, select Abort Scan.
• On the Scan swipe screen, select Abort Scan.
• From the trigger mode indicator on the home screen, select Abort Scan.
