Detecting calibration errors
If an error occurs during any calibration step, the Model 2182 will generate an appropriate
error message. Several methods to detect calibration errors are discussed below.
Reading the error queue
As with other Model 2182 errors, any calibration errors will be reported in the error queue.
(You can read the error queue by using the :SYST:ERR? query.)
Error summary
Table B-5 summarizes calibration errors.
Table B-5
Calibration errors
Error number Error message
+400 "10m vdc zero error"
+401 "1 vdc zero error"
+402 "10 vdc zero error"
+403 "100 vdc zero error"
+404 "10 vdc full scale error"
+405 "-10 vdc full scale error"
+406 "100 vdc full scale error"
+408 "10 vdc ch2 high zero error"
+409 "10 vdc ch2 low zero error"
+410 "B_7_div100 ACAL error"
+411 "B_0_div100 ACAL error"
+412 "B_7_1 ACAL error"
+413 "B_0_1 ACAL error"
+414 "B_1_1 ACAL error"
+415 "B_1_10 ACAL error"
+416 "ACAL not open-circuit"
+417 "B_P1_10 ACAL error"
+418 "B_P1_100 ACAL error"
+419 "B_0_10 ACAL error"
+420 "Analog output zero error"
+421 "Analog positive gain error"
+422 "Analog negative gain error"
+423 "B_0_100 ACAL error"
Calibration Reference B-11
