Front-panel user interface overview
The front-panel user interface gives you quick access to measurement
settings, system configuration, instrument status, and other functions.
Home-screen overview
The Series 2230G runs a self-test automatically when it is turned on. If the
self-test finishes with no errors, the screen below is displayed.
The first line on the home screen displays the voltage settings of all three
channels.
The second line on the home screen displays the current settings of all
three channels. The SV indicator informs the user that the display is
showing programmed settings.
Menu screen overview
When you press the key on the front panel, the system menu
screen is displayed.
The following options are displayed:
Default Set
Enable Channels
Protection Settings
Track
Combine
User Settings
System Info
Select an item by pressing the key, and then configure the
parameters.
0.000V 0.000V 0.000V
SV
0.000A
SV
0.000A
SV
0.000A
