Keithley 2461 User Manual

Menu screen overview
When you press the MENU key on the front panel, the Menu screen
is displayed.
From this screen, you can select source, measure, graphing, trigger,
scripting, and system setup menus. These menus allow you to choose
options to set up your instrument to meet the needs of your
applications.
An example of the options that are available when you select the
Settings option under Measure is shown below.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
