Keithley 2461 User Manual

The voltage measurements appear in the Measure Voltage area of the
Home screen.
To save the data to a USB flash drive:
1. Insert a USB flash drive into the front panel USB connector.
2. Press the MENU key.
3. Under Measure, select Reading Buffers.
4. Select defbuffer1. A menu is displayed.
5. Select Save To USB.
6. Enter the file name.
7. Select OK (on the screen).
8. A confirmation message is displayed. Select Yes.
The instrument saves the data to a .csv file on the flash drive.

Keithley 2461 Specifications

General

Maximum Current	7 A
Power	100 W
Resolution	6.5 digits
Source Measure Unit (SMU)	Yes
DC Voltage	100 V
Maximum Voltage	100 V
Display	5-inch capacitive touchscreen
Connectivity	USB, GPIB
Software	TSP
DC Current	7 A
Current Source Range	0 to 7 A
Voltage Measurement Range	100 mV to 100 V
Current Measurement Range	10 nA to 7 A
Voltage Measurement Resolution	100 nV
