Keithley 2601

Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
www.keithley.com
Specifications are subject to change without notice.
SPEC-2601_2602 Rev. D / January 2008 Page 5 of 7
Models 2601/2602
System SourceMeter
®
Specifications
Contact Check
9
Speed
Maximum measurement time to
memory for 60Hz (50Hz)
9
Accuracy (1 year)
23°C +
5°C
+
(% rdg.+ ohms)
Fast 1 (1.2)ms 5% + 10
Medium 4 (5)ms 5% + 1
Slow 36 (42)ms 5% + 0.3
Additional Meter Specifications
Load impedance: Stable into 10,000pF typical.
Common mode voltage: 250VDC.
Common mode isolation: >1G, <4500pF.
Over-range: 101% of source range, 102% of measure range.
Maximum sense lead resistance: 1k for rated accuracy.
Sense input impedance: >10G.
9 Includes measurement of SENSE HI to HI and SENSE LO to LO contact resistances.
