Model 2635/2636
System SourceMeter
®
Specifications
4. GENERAL
Specifications Category Specifications
Host Interfaces Computer control interfaces
IEEE-488
IEEE-488.1 compliant. Supports IEEE-488.2 common commands
and status model topology
RS-232
Baud rates from 300bps to 115200bps. Programmable number of
data bits, parity type, and flow control (RTS/CTS hardware or
none). When not programmed as the active host interface, the
SourceMeter can use the RS-232 interface to control other –
instrumentation
Expansion Interface
The TSP-Link expansion interface allows TSP enabled
instruments to trigger and communicate with each other.
Cable Type Category 5e or higher LAN crossover cable
Length 3 meters maximum between each TSP enabled instrument
Digital I/O Interface See 2601/02 GENERAL specifications for circuit diagram
Connector 25-pin female D
Input/Output Pins 14 open drain I/O bits
Absolute Maximum
Input Voltage
5.25 V
Absolute Minimum
Input Voltage
– 0.25 V
Maximum Logic Low
Input Voltage
0.7V, +850 µA max
Minimum Logic High
Input Voltage
2.1V, + 570 µA
Maximum Source
Current (flowing out of
Digital I/O bit)
+ 960 µA
Maximum Sink Current
@ Maximum Logic Low
Voltage (0.7V
– 5.0 mA
Absolute Maximum
Sink Current (flowing
into Digital I/O pin
– 11 mA
5V Power Supply Pin Limited to 600 mA, solid state fuse protected
Safety Interlock Pin
Active high input. > 3.4 V @ 24 mA (absolute maximum of 6 V)
must be externally applied to this pin to insure 200 V operation.
This signal is pulled down to chassis ground with a 10 K resistor.
200 V operation will be blocked when the INTERLOCK signal is
<_0.4 V (absolute minimum –0.4 V). See figure below:
Specifications are subject to change without notice.
SPEC-2636_2636 Rev. A / September 2007 Page 7 of 8
