Keithley 2651A Quick Start Guide

Operating the instrument on an incorrect line voltage
may cause damage to the instrument, possibly
voiding the warranty.
To connect line power:
1. Make sure the front panel power switch is in the off (0) position.
2. Connect the socket of the supplied power cord to the power
connection on the rear panel.
Connect power line cord
3. Connect the plug of the power cord to a grounded AC outlet.
Turn on the instrument
Turn on the instrument by pressing the front panel POWER switch
to the on (|) position.
Safety
Unpack Connect
FAQs
Next steps
Introduction Test

Keithley 2651A Specifications

General

Maximum Voltage	40 V
Current Range	0 to 3 A
Resolution	6.5 digits
Resolution (Current)	100 pA
Minimum Current Resolution	100 pA
Power	300 W
Display	5.7-inch color LCD
Type	SourceMeter
Communication Interfaces	USB, GPIB, Ethernet
Interfaces	GPIB, USB, Ethernet
Accuracy (Voltage)	0.02% + 3 mV
Resolution (Voltage)	100 nV
Minimum Voltage Resolution	100 nV
