Keithley 2651A Quick Start Guide

1
3
2
10
11
12
5
6
7
8
4
9
9 Model 2651A-KIT-1 (low-impedance/high-current coaxial cable)
Refer to the packing list for additional items that might have shipped
with your instrument.
In addition to the Model 2651A High Power System SourceMeter
®
Instrument, you should have received:
7 Male direct plug-in connector for low-impedance/high-current
output
2 Model 2651A Product Information and Test Script Builder
CD-ROMs
8 Female terminal block extender for use with 8-pin signal
control cable
6 Female terminal block extender for use with the
Model 2651A-KIT-1
5 Interlock DB-25 male connector kit hardware
11 Safety Standards Conformance Information
1 Model 2651A Quick Start Guide
4 RJ45 LAN crossover cable
10 8-pin signal control cable
12 Optional rack-mount kit
3 Power line cord
