VOLTAGE SOURCE
(Model 487)
CAUTION
The voltage source may float. However,
neither V-Source terminal may ever be
more than 500V above chassis.
V-SOURCE OUTPUT
500V MAX TO ,& OR.+
I HI
LO 1
5oov
MAX
Figure 3. Model 487 V-Source Output Terminals
Table 3. Model 487 V-Source
