V-SOURCE
V-SOURCE
DISPLAY
I
ADJUST
El
A
OPERATE
rl
cl
7mA MAX
DESCRIPTION
This feature delivers - 102.35V to + 102.4OV at a maximum of f2mA
to the V-SOURCE OUTPUT binding posts on the mar panel of the
Model 617.
OPERATION
WARNING
Hazardous voltages may be present at the output.
Make sure that the OPERATE indicator light is off
before connecting the V-SOURCE OUTPUT to a
load.
20
