Model 6220/6221 User’s Manual Wave Functions (6221 Only) 7-9
Return to Section 7 topics
MORE Expand to show additional menu items:
TRIG-MODE
MAN/BUS
NONE
TLNK-#1
#2
#3
#4
#5
#6
Configure low jitter external waveform triggering:
2
Disable external trigger mode (default).
Enables external trigger mode with no line selected.
Enables external trigger on trigger link line 1.
Enables external trigger on trigger link line 2.
Enables external trigger on trigger link line 3.
Enables external trigger on trigger link line 4.
Enables external trigger on trigger link line 5.
Enables external trigger on trigger link line 6.
RE-TRIG
IGNORE-TRIG
RESTART-IMMEDIATELY
Configure response to external retriggering:
Ignore subsequent triggers while outputting a wave.
Restart waveform immediately upon each trigger.
INACTIVE-VAL Set output value before and after triggered waveforms.
Table 7-2 (cont.)
Wave function configuration menu
Menu selection Description
1. Arbitrary waveforms can be defined only via remote. Location 0 is volatile RAM, while locations 1-4 are
NVRAM and will be saved across power cycles.
2. Waveform triggering available in revision level A03 and later firmware. See Section 7 of the Model 6220/
6221 Reference Manual for details on externally triggering waveforms.
