3
DC Current Source Operation
Section 3 topics
Current source output capabilities, page 3-2
Source ranges, page 3-2
Compliance, page 3-3
Output power (source or sink), page 3-3
Output response, page 3-5
Setting source and compliance, page 3-8
Source and compliance editing, page 3-8
Sourcing current, page 3-12
Remote programming – source output commands, page 3-15
NOTE The information in this section is an abbreviated version of
the information in Section 3 of the Reference Manual. Refer
to Section 3 of the Reference Manual for complete details and
additional information that is not provided in this manual.
NOTE Supplied example software allows you to control a Model
622x from any PC using simple mouse clicks through a virtu-
al front panel. For details, see “Using the example software”
in
Section 10 of the Reference Manual.
