S530/S540 KTE Linear Parametric Test Library (LPTLib) User's Manual Section 3:
LPTLib command reference
S530-900-01 Rev. E / September 2017 3-77
Modifiers that affect source-measure unit (SMU) behavior
Modifier Value Comment
KI_AVGMODE
26xx:
KI_INTEGRATE
KI_MEASX
Controls the behavior of the
avgX command call.
KI_INTEGRATE replaces the
avgX command with the intgX
command.
KI_MEASX replaces the avgX
command with the measX
command.
KI_HIGHC_MODE
26xx: 0 or 1
0 = Disable High C mode
1 = Enable High C mode
KI_IMTR
Sets up a source-measure unit
(SMU) as a current meter. The
ranges used are representative
of the type of instrument being
simulated. Note that this
setmode turns on the source.
KI_S400
Sets a SMU to use ranges
equivalent to the S400.
KI_DMM
Sets a SMU to use ranges
equivalent to a DMM. Provides a
lower resolution, fast
measurement. Used for
high-current applications.
KI_ELECTROMETER
Sets a SMU to use ranges
equivalent to an electrometer.
Provides the best measurement
resolution but slower
measurement time. Used for
low-current applications.
KI_INTGPLC
CMTR: 0.006 to 10.002
24xx: 0.01 to 10 (S530 only)
26xx: 0.001 to 25
Defines a period in terms of AC
line cycles over which
measurements are averaged.
KI_LIM_INDCTR
Any
Controls what measure value is
returned if the SMU is at its
programmed limit. The devint
command default is
SOURCE_LIMIT (7.0e22).
Note that the SMU always
returns INST_OVERRANGE
(7.0e22)
if it is on a fixed range
that is too low for the signal
being measured.
KI_LIM_MODE
KI_INDICATOR
KI_VALUE
Controls whether the SMU
returns an indicator value when
in limit or overrange, or the
actual value measured. The
default mode after a devint
command is to return a value.
