Keithley System SourceMeter 2601B User Manual

Models 2601B, 2602B and 2604B System SourceMeter
®
Instrument Specifications
Specifications are subject to change without notice
2 of 13 SPEC-2602B Rev. B / February 2014
VOLTAGE ACCURACY SPECIFICATIONS
2,3
Range
Source Measure
Programming
resolution
Accuracy
± (% reading + volts)
Typical Noise
(Peak to Peak)
0.1 Hz to 10 Hz
Display
resolution
Accuracy
4
± (% reading + volts)
100 mV 5 µV 0.02 % + 250 µV 20 µV 100 nV 0.015 % + 150 µV
1 V 50 µV 0.02 % + 400 µV 50 µV 1 µV 0.015 % + 200 µV
6 V 50 µV 0.02 % + 1.8 mV 100 µV 1 µV 0.015 % + 1 mV
40 V 500 µV 0.02 % + 12 mV 500 µV 10 µV 0.015 % + 8 mV
CURRENT ACCURACY SPECIFICATIONS
2
Range
Source Measure
Programming
resolution
Accuracy
± (% reading + amperes)
Typical Noise
(Peak to Peak)
0.1 Hz to 10 Hz
Display
resolution
Accuracy
4
± (% reading + amperes)
100 nA 2 pA 0.06 % + 100 pA 5 pA 100 fA 0.05 % + 100 pA
1 µA 20 pA 0.03 % + 800 pA 25 pA 1 pA 0.025 % + 500 pA
10 µA 200 pA 0.03 % + 5 nA 60 pA 10 pA 0.025 % + 1.5 nA
100 µA 2 nA 0.03 % + 60 nA 3 nA 100 pA 0.02 % + 25 nA
1 mA 20 nA 0.03 % + 300 nA 6 nA 1 nA 0.02 % + 200 nA
10 mA 200 nA 0.03 % + 6 µA 200 nA 10 nA 0.02 % + 2.5 µA
100 mA 2 µA 0.03 % + 30 µA 600 nA 100 nA 0.02 % + 20 µA
1 A 20 µA 0.05 % + 1.8 mA 70 µA 1 µA 0.03 % + 1.5 mA
3 A 20 µA 0.06 % + 4 mA 150 µA 1 µA 0.05 % + 3.5 mA
10 A
5
200 µA 0.5 % + 40 mA N/A 10 µA 0.4 % + 25 mA
2
For temperatures 0 °C to 18 °C and 28 °C to 50 °C, accuracy is degraded by ± (0.15 × accuracy specification)/°C. High Capacitance Mode
accuracy is applicable at 23 °C ± 5 °C.
3
Add 50 µV to source accuracy specifications per volt of HI lead drop.
4
Derate accuracy specification for NPLC setting < 1 by increasing the error term. Add appropriate typical percent of reading term for resistive
loads using the table below.
NPLC setting 100 mV range 1 V and 40 V ranges 100 nA range 1 µA to 100 mA ranges 1 A to 3 A ranges
0.1 0.01 % 0.01 % 0.01 % 0.01 % 0.01 %
0.01 0.08 % 0.07 % 0.1 % 0.05 % 0.05 %
0.001 0.8 % 0.6 % 1 % 0.5 % 1.1 %
5
10 A range is accessible in pulse mode only. Accuracy specifications for 10 A range are typical.
