Models 2601B, 2602B and 2604B System SourceMeter Instrument Specifications
Specifications are subject to change without notice
SPEC-2602B Rev. B / February 2014 9 of 13
Maximum measurement
range change rate
> 7000 per second for > 10 µA. When changing to or from a range ≥ 1 A, maximum rate
is > 2200/second.
Maximum source range
change rate
> 400 per second > 10 µA. When changing to or from a range ≥ 1 A, maximum rate is >
190/second.
Maximum source function
change rate
> 1000 per second
Command processing time
< 1 ms
 Maximum time required for the output to begin to change after receiving the
smua.source.levelv
or
smua.source.leveli
command.
TRIGGERING AND SYNCHRONIZATION CHARACTERISTICS
Triggering
Trigger in to trigger out
0.5 μs
Trigger in to source
change
22
10 μs
Trigger timer accuracy
±2 μs
Source change
22
after LXI
trigger
280 μs
Synchronization
Multi-node synchronized
source change
22
< 0.5 μs
Single-node synchronized
source change
22
< 0.5 μs
22
Fixed source range with no polarity change.
