Technical specications
Property Parameter Condition Value Unit
Battery capacity
≥ 2300 mAh
Voltage 3,7 V
Type Li-ion
Bluetooth version 3.0 Classic
Range up to 10 m (class 2)
USB plug type Mini USB male
USB version 2.0
External power supply USB 5 ± 5% VDC
End consumer power supply U-Out 15 VDC ± 5%
End consumer power supply I-Out > 100 mA
Voltage measurement input U-In 0–12 VDC
Accuracy of voltage measurement input
U-In RI ≥ 100 kΩ 0.3 %FS
Resolution of voltage measurement input U-In < 0.004 V
Current measurement I-Out 0–150 mA
Accuracy of current measurement I-Out 0,3 %FS
Resolution of current measurement I-Out < 0.04 mA
RS485 conguration parameters Bus address 253
RS485 bus devices 1/4 unit load up to 128
RS485 transmission rate 9600 (default) / 115200 baud
RS485 cable length 0,75 m
Protection IP 40
Storage and operating temperature -10…+50 °C
Dimensions (H x W x D) 95 x 28 x 65 mm
Weight 150 g
Battery/charging
In order to protect the battery in the device, the user should switch off the converter after use. In battery operation,
the K-114 BT switches off automatically after communication has been inactive for 30 minutes.
The battery can be charged via the USB interface. Care must be taken to ensure that the battery can be charged
both via a normal USB port and a DCP (dedicated charging port) or USB adapter. This has the benet that instead
of being charged with 500 mA or 100 mA (USB port), the battery can be charged with up to 1 A (DCP), reducing
the charging time.
Charging and operating times (90%):
Table 1: Battery charging times
Table 2: Operating times with the battery
Charging time Value Unit
Charging time @ 100 mA (USB/low-powered port) ≈ 22,5 [h] hours
Charging time @ 500 mA (USB/high-powered port) ≈ 4,5 [h] hours
Charging time @ 1 A (DCP) ≈ 2,5 [h] hours
Operating time Value Unit
Operating time without load ≈ 3 [d] days
Operating time with „LEO 3“
≈ 2 [d] days
Operating time with a device with a power consumption of 20 mA ≈ 18 [h] hours
