Remove
Shipping Cotter
Pins
Manual support of the lip must be maintained until the lip
lock is in place. The lip is free to move downward when
it is released unless the lip lock is in position supporting
the lip. DO NOT WORK UNDER THE DOCK LEVELER
RAMP OR LIP UNLESS THE MAINTENANCE STRUT IS IN
PLACE AND PINNED, AND LIP LOCK IS IN PLACE AND
SUPPORTING THE LIP.
Maintenance
strut bracket
clip through
maintenance
strut pin
Maintenance
strut pin
Maintenance
strut
Lip
Lip
lock
