Kelly KLS-H User Manual

5
2.3 Specifications
•Frequency of Operation: 10KHz or 20KHz.
•Standby Battery Current: < 0.5mA.
•5V or 12V Sensor Supply Current: 40mA.
•Controller supply voltage range: PWR, 18V to 90V for controllers rated equal or lower than
72V.The PWR can be 96V batteries for KLS96xxx-8080H model.So All KLS-H and KLS-8080H
model are non isolated type controllers.
•Supply Current, PWR, 30mA Typical.
•Configurable battery voltage range, B+. Max operating range: 18V to 1.25*Nominal Voltage.
•Standard Throttle Input: 0-5 Volts(3-wire resistive pot), 1-4 Volts(hall active throttle).
•Throttle Input: 0-5 Volts. Can use 3-wire pot to produce 0-5V signal.
•
•Full Power Operating Temperature Range: 0℃ to 70℃(MOSFET temperature).
•Operating Temperature Range: -40℃to 100℃ (MOSFET temperature).
•Max Battery Current :Configurable.
2.4 Name Regulation
The name regulation of Kelly BLDC motor controllers:
KLS 72 30H
KLS:Kelly BLDC motor controller based on sinusoidal waveform which is supposed to
work with BLDC motor with three hall sensors.All KLS controllers can do regen brake
function by default.
72:72V batteries.
H:The motor controller included a plastic cover with a fuse.And KLS-H is IP66 rating
without filling the silica gel by default.But KLS-8080H is IP54 rating.
C:BroadCast type CAN bus protocol.
Kelly KLSH Brushless Motor Controller
Model
30 seconds
Current(Amp)
Continuous
Current(Amp)
Voltage(Volt)
KLS6022H
220
88
24-60
KLS6030H
350
120
24-60
KLS7215H
150
60
24-72
KLS7218H
200
80
24-72
KLS7222H
220
80
24-72
KLS7230H
300
100
24-72
KLS7245H
350
140
24-72
KLS7250H
400
160
24-72
KLS7275H
500
200
24-72
KLS8415H
150
60
24-84
KLS8422H
220
80
24-84
KLS8430H
300
100
24-84
