Kelly KLS-H User Manual

6
KLS72501-8080H
500
200
24-72
KLS72601-8080H
600
240
24-72
KLS72701-8080H
700
280
24-72
KLS96301-8080H
300
120
24-96
KLS96401-8080H
400
160
24-96
KLS96501-8080H
500
200
24-96
KLS96601-8080H
600
240
24-96
1.60V model: range of the batteries voltage is 18V-80V.
2.72V model: range of the batteries voltage is 18V-90V.
3.84V model: range of the batteries voltage is 18V-105V.
4.96V model: range of the batteries voltage is 18V-120V
Chapter 3 Wiring and Installation
3.1 Mounting the Controller
The controller can be oriented in any position which should be as clean and dry as possible,
and if necessary, shielded with a cover to protect it from water and contaminants.
To ensure full rated output power, the controller should be fastened to a clean, flat metal
surface with four screws. Applying silicon grease or some other thermal conductive material to
contact surface will enhance thermal performance.
Proper heat sinking and airflow are vital to achieve the full power capability of the controller.
The case outline and mounting holes’ dimensions are shown in Figure 1,2,3,4.

Kelly KLS-H Specifications

General

Brand	Kelly
Model	KLS-H
Category	Controller
Language	English
