Kelly Jaguar series KLS-N Sinusoidal Brushless PM Motor Controller User’s Manual V2.9
6
Kelly KLS-N - Sinusoidal Brushless Permanent Magnet Motor Controller
Model
Nominal
Voltage
Max Operating
Voltage
Peak Current**
1 Minute
Continuous
Current
KLS2412ND
12-24V
9-32V
140A
Up to 100A *
KLS2412N
12-24V
9-32V
140A
60A-100A
KLS2418ND
12-24V
9-32V
240A
Up to 135A *
KLS2418N
12-24V
9-32V
240A
80A-130A
KLS2430ND
12-24V
9-32V
280A
Up to 160A *
KLS2430N
12-24V
9-32V
280A
90A-150A
KLS4812ND
36-48V
27-60V
140A
Up to 100A *
KLS4812N
36-48V
27-60V
140A
60A-100A
KLS4818ND
36-48V
27-60V
240A
Up to 135A *
KLS4818N
36-48V
27-60V
240A
80A-130A
KLS4830ND
36-48V
27-60V
280A
Up to 160A *
KLS4830N
36-48V
27-60V
280A
90A-150A
KLS7212ND
48-72V
36-86V
140A
Up to 100A *
KLS7212N
48-72V
36-86V
140A
50A-90A
KLS7215ND
48-72V
36-86V
200A
Up to 110A *
KLS7215N
48-72V
36-86V
200A
60A-110A
KLS7218ND
48-72V
36-86V
240A
Up to 130A *
KLS7218N
48-72V
36-86V
240A
80A-120A
KLS7230ND
48-72V
36-86V
280A
Up to 150A *
KLS7230N
48-72V
36-86V
280A
90A-135A
KLS7240ND
48-72V
36-86V
320A
Up to 160A *
KLS7240N
48-72V
36-86V
320A
90A-150A
KLS7270NE
48-72V
36-86V
450A
150A-225A
KLS8430ND
48-84V
40-100V
280A
Up to 150A *
KLS8430N
48-84V
40-100V
280A
90A-135A
Note: *Depends on conductive heat sink
**Peak current can be prolonged with additional heat sink, easily over 2 minutes.
