C2N Series Tankless Heater Installation
5/3/2016 Bradley • 215-1821 Rev. B; ECN 16-17-005
Electric Installation
3
WARNING Failure to properly ground the unit(s) per the National Electric Code could result in injury
or death.
B
Using a hole punch, cut a hole the proper
size for conduit connection; large enough
for the wire size for each heater. The
connectors need to be rated NEMA4/4X
to ensure proper sealing of the enclosure.
A
Open enclosure door.
C
Run wires through the appropriate size
conduit.
D
Connect wires to the system terminal
block or fused disconnect inside the
enclosure.
E
Connect the ground wire to the stud
provided with the “Ground” label beneath it.
NOTICE! Any option that requires field wiring
must be done with 600V cable per the
schematic that was shipped with the
heater.
NOTICE! Use a 4-core cable or multi-stranded
machine tool wire from an approved
isolating 3-pole switch or circuit
breaker.
NOTICE! Make sure the electrical cable is the
correct size to carry 100% of the full
load current. See table for proper
wire sizes.
WARNING All Keltech heaters must be fused in accordance with National Electric Code (NEC) for the
full load amperage listed on the nameplate rating for each heater.
ELECTRICAL SPECIFICATIONS FOR HEATER (3 Phase)
Model Voltage Amps kWatts
Min Wire
Size
C2N363/600D 600 35 36 6 AWG*
C2N503/600D 600 49 50 4 AWG*
C2N363/480D 480 43 36 6 AWG*
C2N503/480D 480 60 50 3 AWG*
C2N363/415D 415 38 27 6 AWG*
C2N503/415D 415 52 37 4 AWG*
C2N363/400D 400 36 25 6 AWG*
C2N503/400D 400 50 35 4 AWG*
C2N363/380D 380 33 23 8 AWG*
C2N503/380D 380 47 31 4 AWG*
* Based on the NEC Table 310.15 for 75°C insulated copper wire @ 30°C
Ambient. Aluminum wire requires larger gauges.
WARNING Install product to rated line voltage in accordance to current local and national codes and
regulations.
Not all available (optional) voltages are listed in table.
