Keltech KRAD M Series - Electrical Diagram (KRAD 40 M - KRAD 125 M)

Page 24
6.2 ELECTRICAL DIAGRAMS
KRAD 40M to KRAD 125M
A20
M
l
~
A/S
C/C
P/R
K01
P
A40-1
M01
DR K01 K30
S16 NT
1
2
3
4 5
6 7 9 10 11 12
L
N
~
HP
S10
M
l
~
M10
HP
S11
ELECTRICAL SUPPLY LINE
SINGLE PHASE + PROTECTION EARTH
CABLES SIZE
ELECTRICAL
SPECIFICATIONS
COMPRESSOR
UN 230V/1~/50Hz
MKP-66 RLA 1,6A 0,240kW MKP-96 RLA 2,5A 0,393kW MKP-130 RLA 3,1A 0,484kW MKP-168 RLA 4,0A 0,620kW MKP-240 RLA 5,7A 0,870kW
FAN MOTOR UN 230V/1~/50Hz MKP-66 RLA 0,20A 0,035kW MKP-96 RLA 0,68A 0,095kW MKP-130 RLA 0,68A 0,095kW MKP-168 RLA 0,68A 0,095kW MKP-240 RLA 0,68A 0,095kW
S01 MAIN PROTECTION AND DISCONNECTING MEANS SHALL BE PROVIDED BY THE INSTALLER OF RESIDUAL CURRENT AUTOMATIC CIRCUIT BREAKER
MKP-66 MKP-96 MKP-130 MKP-168 MKP-240
3x1,5mm2 3x1,5mm2 3x1,5mm2 3x1,5mm2 3x1,5mm2
1
4
1
4
3
4
2
4
19
4
4
4
3
10
10
10
12
11
SP
EV3
FIELD INSTALLED
MAXIMUM SET: %15
EV3: Controller
SP: Power supply AL: Alarm contacts A20: Drain supply DR: Drain valve relay A40-1:Start capacitor K01: Compressor start relay K02: Compressor motor contactor
K30: Alarm relay
S10: Fan pressure switch S11: High pressure switch S16: Filter service contact (optional) M01: Compressor motor M10: Fan motor P: Compressor motor overload protector NT: Temperature sensor (NTC) HP indicates high pressure
5
6
7
AL
PE
