Kelvinator KCT45036A Installation Manual

Kelvinator solar hot water systems specications 5
Specifications
Solar controller (KKSSUA)
Dimensions (mm) length 365mm x width 205mm x depth 100mm
Protection rating IPX4
Net weight 2.3kg
Operating positive pressure. max. 850kPa
Maximum water temperature 95°C
Circulation pump type UP15 – 14B
Circulation pump power 25W
Rated voltage of circulation pump AC 220-240V
Frequency 50Hz
Model number
KCT27000A
KCT27036A
KCT34000A
KCT34036A
KCT45036A
Diameter (mm) 648 648 730
Height (mm) 1390 1690 1715
Tank capacity (L) 270 340 450
Net Weight (kg) 95 110 140
Tank wall thickness (mm) 2.5 3 3
Element rating (if installed) 3.6kW 3.6kW 3.6kW
PTR valve pressure limit (kPa) 850 850 850
PTR valve temperature limit (°C) 99 99 99
PTR max energy release rate (kW) 10 10 10
