components list Kelvinator solar hot water systems 9
Components list
Supplied in kit: KKSSF2MA –
flat panel double roof mounting kit
Item No. Qty. Description
1 1 rail bottom for 2x flat panel collector
2 2 strap rail bottom
3 4 clamp flat panel collector
4 4 bolt, nut and washer assembly
5 2 strap top flat panel collector
6 2 self tapping screw
7 2 connector flat panel collector
Supplied in kit: KKSSF1MA –
flat panel single roof mounting kit
Item No. Qty. Description
8 1 rail bottom for 1x at panel collector
9 1 rail joiner
2 2 strap rail bottom
3 2 clamp flat panel collector
4 2 bolt, nut and washer assembly
5 1 strap top flat panel collector
6 1 self tapping screw
7 2 connector flat panel collector
Supplied in kit: KKSSE1MA –
evacuated tube single roof mounting kit
Item No. Qty. Description
10 1 rail bottom for 1x evacuated tube
collector
2 2 strap rail bottom
11 2 clamp evacuated tube collector
4 2 bolt, nut and washer assembly
12 1 strap top left evacuated tube collector
13 1 strap top right evacuated tube collector
14 2 bracket top evacuated tube collector
6 2 self tapping screw
9 1 rail joiner
Supplied in kit: KCPF20A –
flat panel solar collector
Item No. Qty. Description
15 1 flat panel collector
Supplied in kit: KCPE12A –
evacuated tube solar collector
Item No. Qty. Description
16 1 evacuated tube collector
17 1 connector evacuated tube collector
18 2 connector sleeve support evacuated
tube collector
19 2 connector to 1/2" male for evacuated
tube collector
Supplied in kit: KKSSURA –
roof fittings kit
Item No. Qty. Description
20 2 connector to 1/2" male for at panel collector
21 2 stopper flat panel collector
22 2 union 1/2" female to copper
23 2 t-piece 1/2" female
24 2 nipple 1/2" to 1/2" male
25 1 bush 1/2" male to 3/8" female
26 1 air vent valve 3/8" male
27 1 sensor pocket 1/2" male
28 1 sensor collector with wire 15m
Supplied in kit: KKSSUGA –
ground fittings kit
Item No. Qty. Description
29 1 solar controller
30 4 screw xing solar controller
31 2 bush 3/4" male to 1/2" female
24 5 nipple 1/2" to 1/2" male
23 1 t-piece 1/2" Female
27 1 sensor pocket 1/2" male
32 1 exible tube 1/2" female to 1/2" female
33 1 check valve 1/2" male to 1/2" female
22 2 union 1/2" female to copper
34 1 tempering valve 50°C
Supplied with tank: KCT*****A –
tank and TP&R valve assembly
Item No. Qty. Description
35 1 temperature and pressure relief valve
1/2" male
31 1 bush 3/4" male to 1/2" female
36 1 of
KCT27036A -
270L tank with 3.6kW element
KCT34036A -
340L tank with 3.6kW element
KCT45036A -
450L tank with 3.6kW element
KCT27000A -
270L tank without element
KCT34000A -
340L tank without element
Supplied with gas booster: KGC26S*A – gas booster
Item No. Qty. Description
37 4 screw gas booster xing
38 1 of
KGC26SNA -
26L/min solar gas booster - natural gas
KGC26SLA -
26L/min solar gas booster - LP gas
