4 Installation instructions Kelvinator Air Conditioning
Minimum floor areas
Your air conditioner is designed to condition the air for a
certain range of room sizes, please ensure the selection of
your air conditioner complies with the Kelvinator selection
tool available from www.kelvinator.com.au
This product uses refrigerant R32. Certain levels of
refrigerant require minimum room sizes. Please ensure that
these minimum room sizes are adhered to for standard
installations (7.5m pipe length). If larger refrigerant charges
than standard are used then please consult AS60335.2.40 to
determine the safe minimum floor area for the installation.
Model no. Charge of R32 (g) Minimum floor area (m
2
)
KSV26HRE 710 n/a*
KSV26CRE 710 n/a*
KSV35HRE 970 n/a*
KSV35CRE 970 n/a*
KSV53HRE 950 n/a*
KSV62HRE 1400 1.87
KSV70HRE 1400 1.87
KSV70CRE 130 0 1.61
KSV80HRE 170 0 2.76
*no minimum floor area required for this product
Items required for installation
• Level gauge
• Screw driver
• Electric drill
• Hole core drill ( 55mm / 70mm)
• Flaring tool specically designed for R32 or
R410a refrigerant
• Specied torque wrenches
• Spanner (half union)
• A glass of water
• Hexagonal wrench (6mm)
• Gas-leak detector
• Vacuum pump
• Gauge manifold
• Users manual
• Thermometer
• Multimeter
• Pipe cutter
• Measuring tape
Number
Description Quantity
1 Indoor unit mounting plate 1 fan
2 Clip anchor not supplied
3
Self-tapping screw ST4 x 25
- for KSV70CRE, KSV70HRE & KSV80HRE
- for all other models
10
5
4 Remote control 1
5 Remote control holder 1
6 Screw for remote holder 2
7 Battery (AAA 1.5V) 2
8 Insulation material not supplied
9
Connection piping assembly
(refer to page 5)
varies by
country
10 Insulation hose for refrigerant piping not supplied
11 Wall clamp not supplied
12 Drain hose not supplied
13 Connection power cable not supplied
14
Drain connector (heat pump
model only)
1
15
Drain plug (heat pump with capacity
of over 4500W)
3
16
Thermal insulating pipe for extending
drain hose
1
17 Flare nut (for suction pipe) 1
Note: Other parts necessary for installation besides those
mentioned above must be supplied by the customer/installer.
Components
