Kemppi FastMig MXF 37 Pipe User Manual

EN
2.5.2 Air-cooled system: FastMig X 450 + MXP
1.
4.
5.
10.
6.
8.
2.
3.
7.
9.
V
V
1. Wire feed unit
2. FastMig X 450 power source
3. Gas supply
4. MMA electrode holder
5. Remote control device
6. Air-cooled welding gun
7. Power cable
8. Earth return cable and clamp
9. Measurement cable (from power source to wire feeder)
10. Voltage sensing cable (from wire feeder to work piece)
7
© Kemppi Oy / 1312

Kemppi FastMig MXF 37 Pipe Specifications

General

Brand	Kemppi
Model	FastMig MXF 37 Pipe
Category	Welding System
Language	English
