6. TECHNICAL DATA
6.1. TECHNICAL DATA
TTC 130 TTC 130F TTC 160 TTC 160S
Loading capacity
DC- 40% ED 130A 130A 160A 160A
100% ED - - - - - - - - - - - -
Electrode sizes to be used ø 1,0…2,4 ø 1,0…2,4 ø 1,0…2,4 ø 1,0… 2,4
Voltage class L L L L
Cooling Air Air Air Air
Connection to TIG-unit
Gas/current R R R R
Water - - - - - - - - - - - -
TTC 220 TTC 200W TTC 250W TTC 250WS
Loading capacity
DC- 40% ED 220A - - - - - - - - -
100% ED - - - 200A 250A 200A
Electrode sizes to be used ø 1,0…3,2 ø 1,0…2,4 ø 1,0…4,0 ø 1,0…4,0
Voltage class L L L L
Cooling Air Liquid Liquid Liquid
- min. 1 l/min - min. 1 l/min - min. 1 l/min
In inlet: In inlet: In inlet:
- max. 50 °C - max. 50 °C - max. 50 °C
- min. 1 bar - min. 1 bar - min. 1 bar
- max. 5 bar - max. 5 bar - max. 5 bar
Connection to TIG-unit
Gas/current R R R R
Water - - - Snap connectors Snap connectors Snap connectors
The torch meets the construction and safety requirements according to norm EN 50 078.
CE-marking: CE EN50078
Make sure that the torch being in your use is designed for max. welding current needed by you.
