Kenmore 111 - Reinstalling Left Refrigerator Door; Reinstalling Right Refrigerator Door

15
Reinstalling the Left Refrigerator Door
1.
Lower the door onto the middle hinge.
2.
Fit the top hinge over the mounting holes and align to
proper position before tightening.
Use a 10 mm box end or socket wrench to turn top
hinge fastener to secure the hinge.
3.
Screw top hinge cover into place with a screwdriver.
Reinstalling the Right Refrigerator Door
1.
Lower the door onto the middle hinge.
2.
Fit the top hinge over the mounting holes and align to
proper position before tightening. Use a 10 mm box
end or socket wrench to turn top hinge clockwise to
secure the hinge. Securely reconnect the wire harness.
3.
Screw top hinge cover into place with a screwdriver.
REFRIGERATOR INSTALLATION
