HOW TO REMOVE THE PANTRY DRAWER FRONT
1.
Slide pantry drawer out until it stops. Remove pantry
drawer basket by pulling up and tilting toward
refrigerator until can be removed from the pantry
drawer assembly.
2.
Pull back on the harness cover locking tab on left back
side of pantry drawer front and remove the harness
cover. Push down on tab on top of wire harness to
disconnect it.
3.
Use a 10 mm open end or socket wrench to remove
the bolt connecting the rail to each side of the pantry
drawer front. Tilt pantry drawer front up and remove
from rails. Set pantry drawer front face up on a non-
scratch surface.
CAUTION
: Do not hold the handle when removing or
replacing the pantry drawer. The handle may come off
and could cause personal injury.
REFRIGERATOR INSTALLATION
