Key Qty Description
Manufacturer
Part #
1 1 HOOD HANDLE 2818-2T-6200
2 2 HANDLE BASE RB2818C-00-4001
3 2 SCREW 1/4-20×5/8 in.
4 4 RUBBER GASKET 3219-8082
5 1 HOOD 2818-2T-6000
6 2 SCREW 5/16-18×3/4 in.
7 2 BUSHING 2818-2T-0001
8 2 FLANGE NUT 5/16-18
9 1 TEMPERATURE GAUGE 2818-2T-A301
10 1
WASHER,TEMPERATURE
GAUGE
2518SL-6002
11 1 NUT 5/16-18
12 4 HEAT DIFFUSER 2818-2T-2007
13 2 COOKING GRIDS 2818-2T-2001
14 1 WARMING RACK 2818-2T-2002
15-1 1 IGNITION PIN ( MAIN BURNER ) 2818-2T-A500-4/1
15-2 1 IGNITION PIN ( MAIN BURNER ) 2818-2T-A500-4/2
15-3 1 IGNITION PIN ( MAIN BURNER ) 2818-2T-A500-4/3
15-4 1 IGNITION PIN ( MAIN BURNER ) 2818-2T-A500-4/4
16 4 PIN 1.6×30
17 4 MAIN BURNER SH3118B-2004
18 16 SCREW 5/32-32×3/8 in.
19 1 BURNER BOX 2818-2T-2000
20 1 WIND SHIELD 2818-2T-2004
21 1 RIGHT WING TABLE 2818-2T-5100
22 8 SCREW 1/4-20×3/4 in.
23 4 WING MECHANISM 2818-2T-A200
24 8 SCREW 3/16-24×5/8 in.
25 1 IGNITION SWITCH WIRE 2818-2T-A400
26 1 MANIFOLD,MAIN BURNER 2818-2T-3200
27 1 LP GAS REGULATOR SH3118B-3003
28 1 REAR PANEL 2818-2T-1002
29 1 RIGHT PANEL ASSEMBLY 2818-2T-1400
30 1 BEAM 2818-2T-1200
Key
Qty Description
Manufacturer
Part #
31 1 RIGHT ANGLE BRACKET 2818-2T-1700
32 2 CASTER,LOCKING 2518-3-8007
33 2 CASTER 2518-3-8008
34 1 WING-HEAD SCREW 1/4-20UNC×2 in.
35 1 SCREW W/SHOULDER 5/32-32×3/8 in.
36 1 MATCH HOLDER 3019L-1710
37 1 DOOR(R) 2818-2T-8000
38 1 DOOR(L) 2818-2T-7000
39 1 BOTTOM PANEL ASSEMBLY 2818-2T-1100
40 31 SCREW 3/16-24×3/8 in.
41 1 LEFT ANGLE BRACKET 2818-2T-1600
42 3 MAGNET SH3118-1803
43 1 MAGNET HOUSING 2818-2T-1102
44 2 SCREW 5/32-32×3/8 in.
45 1 ELECTRICAL IGNITER 2818-2T-A600
46 1 IGNITER HOUSING 2818-2T-1302
47 1 LEFT PANEL ASSEMBLY 2818-2T-1300
48 1 DRIP TRAY SUPPORT 2818-2T-1500
49 1 DRIP TRAY 2818-2T-1001
50 4 KNOB E3518-00-3001
51 8 SCREW M4×8
52 4 BEZEL SH3118B-3004
53 4 SCREW 1/4-20×3/8 in.
54 1 CONTROL BOX 2818-2T-3000
55 1 LEFT WING TABLE 2818-2T-4100
To order replacement parts after using grill,
call 1-800-4-MY-HOME
®
If you are missing hardware or have
damaged parts after unpacking grill, call
1-800-482-0131 for replacement.
PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
