Conversion Instructions for 16154
Main Burner Conversion
1. Remove the R pins at the back of main
burners to detach burners from bracket.
Lift back of main burners while sliding
burners out of firebox, disengaging main
burners from valves. (Fig. 1)
2. Insert the provided orifice removal tool (B)
into burner openings and unscrew orifices
from ends of valves. (Fig. 2)
Orifice
Fig. 2
B
Fig. 1
R pin
Back of Firebox
