PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
To order replacement parts after using grill,
call 1-800-241-7548.
14 • 466724112
Key Qty Description Part #
1 1 BACK RAIL G314-0806-W1
2 1 RIGHT LEG ASSEMBLY G314-3800-W2
3 1 LEFT LEG ASSEMBLY G314-3700-W2
4 1 MATCH HOLDER G401-0079-W1
5 1 FRONT PANEL G314-0805-W1
6 1 AXLE ROD G312-0403-W1
7 2 WHEEL G211-0016-W1
8 1 LEG EXTENDER, FRONT G314-1802-W1
9 1 LEG EXTENDER, REAR G314-1804-W1
10 1
TANK EXCLUSION, SHORT
(SILVER)
G314-0809-W1
11 1 TANK EXCLUSION, LONG
(BLACK)
G314-0810-W1
12 1 TOP LID G314-4800-W1
13 1 LOGO PLATE F/ LID G528-0002-W2
14 1 HANDLE F/ TOP LID G314-0101-W1
15 2
SILICONE RUBBER BUMPER,
F/ MAIN LID
G508-0063-W1
16 2 SILICONE REAR RUBBER BUMPER,
F/ MAIN LID
G303-0038-W1
17 1 TOP LID HARDWARE G430-0024-W1
18 1 FIREBOX G314-4500-W1
19 3 MAIN BURNER TUBE
G314-0700-W1A
20 1 ELECTRODE, MAIN BURNER G314-0003-W1
21 2 FLAME CARRY OVER TUBE G314-0307-W1
22 1 MAIN CONTROL PANEL G314-5001-W1
23 1 IGNITOR G206-0301-W1
24 1 HOSE VALVE REGULATOR G314-3500-W1
25 4 CONTROL KNOB
G432-0010-W1
26 4 BEZEL, F/ CONTROL KNOB G314-0005-W1
27 1 RIGHT SIDE SHELF G314-4300-W1
28 1 SIDEBURNER SHELF G314-4000-W1
29 1 DRIP PAN, F/ SIDEBURNER G314-3901-W1
30 1 SIDEBURNER BRACKET G314-3902-W1
31 1 SIDEBURNER G314-4100-W1
32 1 ELECTRODE, F/ SIDEBURNER G430-0042-W2
33 1 ELECTRODE WIRE,
F/ SIDEBURNER
G314-2206-W1
34 1 SIDEBURNER LID G314-3903-W1
35 1 SIDEBURNER GRID G314-2204-W1
Key Qty Description Part #
36 3 HEAT DIFFUSER G314-0303-W1
37 2 COOKING GRATE G314-0304-W1
38 1 SWING AWAY GRATE G314-0002-W1
39 1 CLIP, F/ GREASE CUP G305-0043-W1
40 1 GREASE CUP G430-0033-W1
41 1 TANK RETAINER, WIRE FORM G314-0804-W1
NOT Pictured
… 1 HARDWARE PACK
G31404-B001-W1
… 1 ASSEMBLY MANUAL, ENGLISH
G314-050801-W1
… 1 ASSEMBLY MANUAL, FRENCH
G314-050802-W1
