12
• Place side burner lid onto left side shelf and align hinges holes in back of lid with side shelf holes. Attach side burner lid
assembly to side shelf with #8-32 x3/8" screws and #8-32 hex nuts.
• Place side burner cooking grate and griddle onto side burner shelf.
#8-32X3/8” Screw
Qty. 4
Side Burner Griddle
Side Burner Cooking Grate
#8-32 Hex Nut
Qty. 4
#8-32 Hex Nut
#8-32x3/8"
Screw
24 • 466226113
