Cart Doors
□ Remove the (2) M5x15 Screws pre-installed to each door handle and use then to attach a door handle to each door as
shown.(A)
□ Insert the door bottom pin into the hole in the cart bottom front rail. Push down the door top pin, align it with the hole in the
cart top front rail, and release pin so that it inserts in hole as shown.(B)
□ Repeat this action for each cart door.
( 8 )M 5 X 1 5S c r e w sP r e - a s s e m b l e
24
(8) M5x 15 Screws Pre-Installed
