GENERAL INFORMATION
Thecentralvacuumisdesignedfordrypick-upofhouseholddirtand
dust. Avoid picking up hard or sharp objects with this system to prevent
hose and plastic pipe damage or clogs.
This manual will cover the final steps of installation of the power unit in
yourhome.Itwillalsoprovidethenecessaryinformationformaintenance
andtroubleshooting,intheunlikelyeventthatitwillbeneeded.Ifyou
requirefurtherinformationaboutinstallationorinquiresontheproduct
please contact your local authorized dealer/distributor.
INSTALLATION SAFETY EqUIPMENT
For wall preparations and cover preparations,
safetyequipmentsuchashelmet,gloves,goggles
and hearing protection are recommended.
CAUTION
Usecautionwhendrillingholesinwallsasgaspipelinesandwaterpipes
and electrical wires may be present.
Ifyouhaveanyquestionsregardingtheproduct,spareparts,service,warranty
or anything else, please contact your local authorized dealer or distributor.
GROUNDING INSTRUCTIONS
Thisappliancemustbegrounded.Ifitshouldmalfunctionorbrakedown,
grounding provides a path of least resistance for electrical current to reduce
theriskofelectricalshock.Thisapplianceisequippedwithacordhaving
anequipment-groundingconductorandgroundingplug.Theplugmust
be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING
Improperconnectionoftheequipment-groundingconductorcanresultin
electricalshock.Checkwithaqualiedelectricianorservicepersonifyouare
in doubt as to whether the outlet is properly grounded, or if the outlet does
nottintoanoutlet.Donotmodifytheplugprovidedwiththeappliance.
Thisapplianceisforuseonanominal120voltcircuitandhasagrounding
plugthatlooksliketheplugillustratedinFigureA.Makesurethattheappliance
is connected to an outlet having the same configuration as the plug.
No adapter should be used with the appliance.
NOTE:InCanada,theuseofatemporaryadapter
isnotpermittedbytheCanadianElectricalCode.
WARNING
Ifthesupplycordisdamaged,itmustbereplacedbyaspecialcord
available from your local authorized dealer/distributor.
SERVICE INFORMATION
The instructions in this booklet serve as a guide to routine maintenance. For
additionalinformation,contactyou’renearestauthorizeddealer/distributor.
RATING PLATE
The type, model, and serial numbers are indicated on the rating plate
located on the control panel or motor hood. For prompt and complete service
information,alwaysrefertothesenumberswheninquiringaboutservice.
WARNING
Non-observanceofthesafetydirectionsmayresultinbodilyharm.
PRODUCT DIMENSIONS
Refertopage15-Image1
WASTE OF ELECTRIC AND ELECTRICAL
EqUIPMENT (WEEE)
This symbol on the product or on its packaging indicates that this product
maynotbetreatedashouseholdwaste.Insteaditshouldbehandedover
to applicable collection point for the recycling of electronics and electrical
equipment.Byensuringthisproductisdisposedofcorrectly,youwillhelp
preventpotentialnegativeconsequencesfortheenvironmentandhuman
health, which could otherwise be caused by inappropriate waste handling
of this product. For more detailed information about this product, please
contact your local waste disposal service or the shop where you purchased
the product.
INSTALLATION
Your home is most likely already fitted with the system of plastic pipes
andinletvalvesandyouarereadytoinstallthecentralpowerunit.Ifyour
home is not fitted for a central vacuum system, you can contract to have
theKenmoreCentralVacuumSysteminstalledbyaprofessionalby
contactingyourlocaldealerordistributororchoosetodo-it-yourself.
The central power unit should be located as far away from the general living
area as possible, yet accessible so you can remove the dirt receptacle, reach
the filter, and inspect the central power unit. A typical location would be in a
garage, where you could vacuum your car or garage area, and where emptying
the dirt receptacle and cleaning the filter would be more convenient. Other suit-
able locations are in the basement, laundry room, or ventilated storage room.
CAUTION
Usecautionwhen drilling holes in walls as gas pipelines and water pipes
and electrical wires may be present. Holes in the masonry are only
allowable if through it its standing stability is not impaired. Holes in wood
studsshouldbedrilled.Dependingonwhatmaterialyourhomeis
built with, use the appropriate anchors to hang your power unit. Power unit
simply slides onto mounting bracket and clicks into place.
Refertopage15-Image3
• Placethecentralpowerunitinaplacethatisremovedfromthegeneral
living area. The exhaust should be easy to connect to a ventilation pipe.
Thiscanbedoneregardlessofthehouse’sconstructionmaterial.
• Locatethetwolowvoltagewiresnearthemainpipe.Removethe
insulationfromthelowvoltwire.Insertthelowvoltwireintothespring
loaded low volt connectors. Be certain you comply with your local
electrical codes and regulations.
Refertopage15-Image4
• Makesurethereisadedicatedelectricsocketforthepowerunit.
• PluginyourCVSwiththesuppliedpowercord.
