receptacle, press the buttons on the receptacle handles. Remove and empty
the contents. Return the receptacle by attaching the bucket to the power
unit. To avoid suction loss make sure the receptacle is securely attached.
Refertopage15-Image11
FILTER MAINTENANCE
TheKenmorelterispermanentandselfcleaning.However,ifyouhave
questionsaboutyourpermanentself-cleaninglter,pleasecontactyour
local authorized dealer/distributor.
PAPER BAG FILTERS - OPTIONAL
The volume of the paper bag is 22 liters. A full dust bag reduces the
systemsperformance.Dependingonhowoftenyouuseyourcentral
vacuumsystem,thedustbagmayneedtobechanged2-3times
per year – and can be obtained at your local dealer/distributor.
Instructions for changing the dust bag:
1.Removethepowerunitdirtreceptacle
2. Loosen the dust bag from the intake tube, remove and dispose.
3.Placeandpressthenewdustbagrmlyintothetube.
Turnthedustbag’sopeningtomakeitfastenrmlyonthetube.
4. Put the dirt receptacle back on the central power unit.
IF YOU ExPERIENCE TROUBLE WITH YOUR
KENMORE CENTRAL VACUUM SYSTEM, FOLLOW
THE SUGGESTIONS BELOW BEFORE CALLING
FOR SERVICE.
PARTIAL/TOTAL LOSS OF SUCTION POWER
• Besuredirtreceptacleisonproperly.
• Emptydirtreceptacle.
• Removedebrisfromlter.
• Besureeachinletvalveisproperlyclosed.
CLEAR BLOCKAGE IN PIPES
Blockage in the hose
Plughoseintoanyinletvalve.Ifthereisnosuctionthroughthehoseafter
connecting at a couple of inlets, the blockage is in the hose. To clear the
hoseobstruction,insertabluntinstrumentintothehose(gardenhose,
wooddowel).Youcanalsoattempttoreversethesuctionthroughthe
hose to dislodge the blockage.
Refertopage15-Image12and13
Ifthereisoneinletvalvewithoutnormalsuctionandyouhavechecked
for hose blockage, then the blockage is in the pipe system between the
blockedinletvalveandthepowerunit(seeinstructionsbelow).
Insertthehoseintotheinletvalvewherethereisnosuction;holdyour
handoverthehoseend.Releasehandquickly.Repeatseveraltimes.If
blockagedoesnotclear,contactyournearestKenmoredealer/distributor.
POWER UNIT WILL NOT START
• Checkforblownfuseorcircuitbreakerinmainhouseelectricsupplybox.
• Unplugandcheckallwallinletandlowvoltageconnectionsforloosewires.
• Ifunitstillwillnotstart,contactyournearestauthorizedservice
station/dealer.
POWER UNIT WILL NOT STOP
• Checkinsideeachinletvalveforobstructionoflow-voltagecontacts.
Ifnovisualobstructioncanbedetected,disconnectthecleanerfrom
the power receptacle and contact your nearest service station/dealer.
CENTRAL POWER UNIT SHUTS OFF BY ITSELF
• Removeandthenre-inserthoseintoinletortoggleswitchoff-on
located on hose handle. See “Overload Protection”.
Instructions to install utility inlet – optional
Instructions pour l'installation de la prise utilitaire – optionnelle
PVC pipe Insert (length optional)
Raccord de tuyau en PVC
(longueur facultative)
Power unit
Unité motrice
PVC pipe to system
Tuyau en PVC raccordé
au système
Sweep 90 tee
Té évasé à 90 degrés
Inlet valve (low voltage)
Prise utilitaire
(à basse tension)
Low voltage wire to cleaner control box
Fil à basse tension au panneau de commandes
de l'aspirateur
