1050MD/DM-5090/DM-9090
45
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico 1 : 1050MD
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany 5 : DM-5090
Y : AAFES(Europe) X : Australia M : Other Areas 9 : DM-9090
indicates safety critical components.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
L : Scandinavia K : USA P : Canada R : Mexico 1 : 1050MD
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany 5 : DM-5090
Y : AAFES(Europe) X : Australia M : Other Areas 9 : DM-9090
indicates safety critical components.
D8 MA111 DIODE
D9 ,10 S5688B(TPB5) DIODE
D11 D3SBA20F03 DIODE
D12 MA111 DIODE
D13 UDZ5.6B ZENER DIODE
D14 ,15 MA113 DIODE
D16 UDZ6.2B ZENER DIODE
D17 MA111 DIODE
D18 U1BC44 DIODE
D19 UDZ18B ZENER DIODE
D20 UDZ15B ZENER DIODE
D21 S5688B(TPB5) DIODE
D22 ,23 MA111 DIODE
D26 DA204U DIODE
D28 DAP202U DIODE 1/5
D29 MA111 DIODE
D30 DA204U DIODE 1/5
D31 ,32 MA111 DIODE
D33 DA204U DIODE 9
IC1 ,2 ICP-N10 ANALOGUE IC
IC3 NJM4558M IC(OP AMP X2)
IC4 PST993D-T ANALOGUE IC
IC5 TL431CLP MOS-IC
IC6 KAN03 CUSTOM IC 1/5
IC8 CS5334 MOS-IC 1/5
IC8 ✽ CS5335 MOS-IC 9
IC10,11 NJM4580ED ANALOGUE IC
IC13,14 NJM4580ED ANALOGUE IC
IC21 TC74HCU04AF IC(HEX INVERTER SMD)
IC22 TC74HCU04AF IC(HEX INVERTER SMD) 9
IC23 LC8904Q MOS-IC 9
IC24 KAN03 CUSTOM IC 9
IC25 SM5844AF MOS-IC 9
IC26 TC74HC157AF MOS-IC
IC27 ✽ LC89170M MOS-IC 9
IC28 ✽ UPD784035GC801 MI-COM IC 9
IC29 HM62256BLFP-7T MEMORY IC 9
IC29 HM62256BLFP-8T MEMORY IC 9
IC29 HM62256BLFP12T MEMORY IC 9
IC30 TC74HC373AF IC(8 bit LATCH) 9
IC31 ✽ UPD784215GF508 MI-COM IC
IC32 TC74HC4094AF MOS-IC
IC33 TC74HC373AF IC(8 bit LATCH)
IC34 HM62256BLFP-7T MEMORY IC
IC34 HM62256BLFP-8T MEMORY IC
IC34 HM62256BLFP12T MEMORY IC
IC35 TA8409S MOS-IC
IC36 TC74HCT7007AF IC(HEX BUFFER)
IC37 HD74HCT126FPEL MOS-IC
IC38 TC74HCT7007AF IC(HEX BUFFER)
IC39 TC74VHC244F MOS-IC
Q1 2SD2012 TRANSISTOR
Q1 2SD2061 TRANSISTOR
Q2 2SK246(Y,GR) FET
Q3 UN5219 DIGITAL TRANSISTOR
R302 RK73FB2A473J CHIP R 47K J 1/10W
R303-310 RK73FB2A104J CHIP R 100K J 1/10W
R311 RK73FB2A272J CHIP R 2.7K J 1/10W
R312 RK73FB2A182J CHIP R 1.8K J 1/10W
R313-315 RK73FB2A104J CHIP R 100K J 1/10W 9
R316 RK73FB2A123J CHIP R 12K J 1/10W
R317 RK73FB2A822J CHIP R 8.2K J 1/10W
R318 RK73FB2A333J CHIP R 33K J 1/10W
R319-321 RK73FB2A104J CHIP R 100K J 1/10W
R322,323 RK73FB2A272J CHIP R 2.7K J 1/10W
R324,325 RK73FB2A104J CHIP R 100K J 1/10W 9
R326,327 RK73FB2A182J CHIP R 1.8K J 1/10W
R328-335 RK73FB2A104J CHIP R 100K J 1/10W
R336 RK73FB2A272J CHIP R 2.7K J 1/10W
R337 RK73FB2A102J CHIP R 1.0K J 1/10W
R338 RK73FB2A104J CHIP R 100K J 1/10W 9
R339,340 RK73FB2A104J CHIP R 100K J 1/10W
R341 RK73FB2A104J CHIP R 100K J 1/10W 9
R342 RK73FB2A182J CHIP R 1.8K J 1/10W
R343 RK73FB2A104J CHIP R 100K J 1/10W
R344 RK73FB2A102J CHIP R 1.0K J 1/10W
R345-348 RK73FB2A104J CHIP R 100K J 1/10W
R349-351 RK73FB2A103J CHIP R 10K J 1/10W
R353 RK73FB2A103J CHIP R 10K J 1/10W
R354 RK73FB2A104J CHIP R 100K J 1/10W
R355,356 RK73FB2A102J CHIP R 1.0K J 1/10W
R357,358 RK73FB2A104J CHIP R 100K J 1/10W
R359 RK73FB2A331J CHIP R 330 J 1/10W
R360 RK73FB2A104J CHIP R 100K J 1/10W
R361,362 RK73FB2A104J CHIP R 100K J 1/10W 9
R363-365 RK73FB2A104J CHIP R 100K J 1/10W
R366 RK73FB2A104J CHIP R 100K J 1/10W 9
R368,369 RK73FB2A104J CHIP R 100K J 1/10W 9
R370 RK73FB2A473J CHIP R 47K J 1/10W
R371 RK73FB2A114J CHIP R 110K J 1/10W 9
R372 RK73FB2A104J CHIP R 100K J 1/10W
R375-378 RK73FB2A104J CHIP R 100K J 1/10W
R379-385 RK73FB2A101J CHIP R 100 J 1/10W
R386-389 RK73FB2A102J CHIP R 1.0K J 1/10W
R390 RK73FB2A331J CHIP R 330 J 1/10W
R391 RK73FB2A104J CHIP R 100K J 1/10W 9
R393 RK73FB2A104J CHIP R 100K J 1/10W 9
R394 RK73FB2A101J CHIP R 100 J 1/10W
W1 -3 R92-0670-05 CHIP R 0 OHM 1/5
W4 R92-0670-05 CHIP R 0 OHM 9
W5 R92-0670-05 CHIP R 0 OHM 1/5
W6 -7 R92-0670-05 CHIP R 0 OHM 9
W8 R92-0670-05 CHIP R 0 OHM
D1 D3SBA20F03 DIODE
D2 DA204U DIODE
D3 U1BC44 DIODE
D4 MA111 DIODE
D5 UDZ5.1B ZENER DIODE
D7 UDZ2.7B ZENER DIODE
! @
