30 DNX520VBT
Multi Function
[1/2] Switches the multi function display.
[
] Closes the multi function bar.
[
] Opens the multi function bar.
[MUSIC] Displays the list of music category.
[VIDEO] Displays the list of video category.
[REP] Repeats the present file or data.
[RDM]* Starts or stops Random play.
[ARDM]* Starts or stops Album Random Play
(plays randomly from current album).
[INFO] Displays information screen of music/
video being played.
[LINK]*
MUSICMUSIC
Searches for another song of
the currently selected artist. See <Link Search>
(page 31).
⁄
* Disabled when VIDEO is being played.
Source Control Screen
Switches to the source control screen to use
various playback functions.
Display the Source 1 Control Screen
See <How to Display the Source Control
Screen> (page 14).
Operation on the Source Control Screen2
1
1
1
[38] Plays or pauses.
[1], [¡] Fast Forwards or Fast Backwards.
[4], [¢] Selects Music/Video.
[List] Displays the iPod list. (page 31)
[
] Switches to the playback screen.
1 Information display
Selects the Title, Artist Name, Album Name
or iPod Name.
"##### / #####" Total number of music in
the iPod and the music number display
"3" Play Mode Display
"P" Play Time Display
[
] When appears, the text display is
scrolled by touching it.
iPod Control
B64-4644-0000VWEEn.indd30B64-4644-0000VWEEn.indd30 09.12.222:43:01PM09.12.222:43:01PM

Kenwood DNX520VBT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	3D
GPS receiver	sensitivity
Channels quantity	5.1 channels
Display diagonal	7 \
Display resolution	800 x 480 pixels
Native aspect ratio	16:9
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WMA
Video formats supported	DivX
DIN size	2 DIN
Product color	Black

Weight and Dimensions

Depth	160 mm
Width	182 mm
Height	112 mm
Weight	1900 g
