Kenwood DNX5280BT Quick Start Guide

17
DNX7280BT/DNX5280BT/DNX4280BT/DNX5580BT
How To Play Music
You can play audio files from music CD, disc media, USB storage device, SD card
and iPod.
NOTE
• For details on playable file format, media format, iPod model, etc., refer to the Instruction Manual.
1
Connect the media you want to play as show below.
Disc
0
iPod, USB device
SD card
0
1) Press the <0> button for 1 second
to open the front panel.
2) Insert the disc into the slot.
1) Insert the disc into the slot.
Playback starts.
 To eject the disc:
Press the <0> button. For ,
the panel should be closed.
1) Connect the device with each
cable.
Playback starts.
 To disconnect the device:
Touch [ ] on the screen and
then touch [ 0 ] for 1 second.
Disconnect the device from the
cable.
DNX7280BT
1) Press [0] for longer than 1 second
to open the front panel and insert
the card.
DNX5280BT
1) Detach the front panel and insert
the card.
Playback starts.
 To eject the card:
Push the card until it clicks and
then remove your finger from the
card. The card pops up so that you
can pull it out.
Notched section
Labeled side
Continued
B59-2048-00_00_DNX7_E_en.indd 17 10/12/16 12:11

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
